Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder Description:
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al powder is a kind of nickel-based superalloy powder with excellent properties. Produced by argon atomization, the powder has excellent corrosion resistance and oxidation resistance. It maintains impressive tensile, yield and creep fracture properties even at temperatures up to 700°C(1300°F). The static properties of the components fabricated by powder bed fusion laser beam (PBF-LB) are comparable to those of AMS 5662 bars at room temperature. These properties make Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al powder an excellent choice for demanding applications in aerospace and power generation gas turbines, as well as a variety of other industrial components.
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder Specifications:
|
Nominal Chemistry
|
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al
|
|
Nom. Particle Size Distr.(µm)
|
-45 +15
|
|
Morphology
|
Irregular
|
|
Liquidus Temperature (°C)
|
1340
|
|
Solidus Temperature (°C)
|
1260
|
|
Max. Service Temperature (°C)
|
760
|
|
Range of Apparent Density (g/cm3)
|
4.0
|
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder Applications:
1. Aerospace components: Ideal for gas turbine components such as blades, blades and combustion chambers due to their high temperature strength and resistance to oxidation and corrosion.
2. Power generation: For power generation turbines and components, durability and high temperature performance are critical.
3. Aerospace body parts: suitable for some aerospace body parts that require high strength, oxidation resistance and structural integrity.
4. High temperature industrial equipment: suitable for industrial equipment and machinery working at high temperatures, requiring heat degradation and mechanical stress.
5. Engine components: Effective for various engine components exposed to high temperatures and harsh working conditions, ensuring long-term performance and reliability.
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder Packing:
Our Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder is carefully handled during storage and transportation to preserve the quality of our product in its original condition.
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder FAQ:
Q1: What are the main benefits of using Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al powder?
A1: This powder has excellent corrosion and oxidation resistance, excellent tensile, yield and creep fracture properties, and maintains performance at high temperatures up to 700°C(1300°F), making it ideal for demanding aerospace and power generation applications.
Q2: Which components are suitable for Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al powder?
A2r: Suitable for aerospace gas turbine parts, power generation turbines, some aerospace body parts, high-temperature industrial equipment, various engine parts.
Q3: How does Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al powder perform compared to AMS 5662 material?
A3: PBF-LB processed and heat treated materials made from this powder have room temperature static properties comparable to AMS 5662 bars, with similar properties in terms of strength and durability.
